Orbea Rise
If you're looking for an e-bike that's not only equipped with the latest technology but also offers a natural ride, then you've come to the right place. Orbea Rise - An e-bike that has revolutionized the way we think about electric mountain bikes. With the motto "Less E, more bike", Orbea has created an e-MTB that combines lightness with performance to give you the best possible riding experience.
Orbea Wild
Filters
The new Rise: The best just got better
The Rise is ready to revolutionise the lightweight e-bike market segment
The completely redesigned frame is stiffer, has improved
Geometry and more suspension travel. This means that the handling is now even better. The
EP motors from Shimano run with the new RS firmware from Orbea. This is how the
Bike is incredibly natural and offers a maximum torque of 85 Nm. The
The Rise’s custom-built batteries have the highest energy density currently available.
means: massive reach, lightly packaged
The development
The Rise has given Orbea a head start in the lightweight e-bike category. But
Orbea has not sat back. When the first Rise was introduced,
Orbea is already working on the successor models. Dedicated electrical engineers are working on the maximum
from batteries and communication electronics. The technical design took
the framework and tested different approaches with the OOlab team. The result?
The best just got better
The result
The Rise is ready to revolutionize the lightweight e-bike market segment once again. The completely redesigned frame is stiffer , has improved geometry and more suspension travel . This means handling is now even better. The EP motors from Shimano run on the new RS firmware from Orbea. This makes the bike ride incredibly natural and offers a maximum torque of 85 Nm . The Rise's custom batteries have the highest energy density currently available. This means: massive range, lightly packed.
What's new?
The Rise is Orbea's lightest e-MTB. Perfect synergy. Every trail, every obstacle and every curve becomes a pleasure.
handling
A holistic driving experience
Low weight and natural support mean lightning-fast reflexes and handling that is fun and lets you become one with the trail.
- Improved rigidity
- Progressive Geometry and Kinematics
- Steep'n'Deep | 200 mm Vario seat post in sizes S and M, 230 mm in sizes L and XL
- More powerful. As light as ever
RS Power
More opportunities to have fun.
“Simple, powerful and lightweight” – the fine balance of these three factors ensures natural support with high elasticity.
Rider Synergy (RS) is the heart of the Rise. The most natural support with a high degree of elasticity and the best batteries currently available for the greatest adventures.
RS GEN2 MC | maximum support, configurable up to 85 Nm | ideal for technical trails, challenging climbs or when you simply need a little more pressure on the pedal.
RS Rage
Break the boundaries!
Smart controls, thoughtful support and the best battery currently available ensure enough range to experience epic adventures.
The perfect battery for your trails
- 420 Wh (standard)
- 630 Wh
The best batteries | 16% more range per gram | more range, no extra weight.
Tuned stiffness
Stiff where it counts: Bicycle frames can be either too stiff or too flexible. When it comes to optimal performance, the right amount of stiffness in the right places is important. Orbea worked hard to increase the stiffness of the front triangle by 8% and the rear triangle by 14%, which creates the perfect balance. Tests have shown that this allows optimal handling: stiff enough for fast cornering and hard braking, but not too stiff, which would reduce traction and lead to faster fatigue when riding.
Asymmetrical design
The new asymmetrical frame design of the Rise, which has already proven itself on the new Occam and Rallon, is a key factor for optimal performance. The position of the mount and the design of the SBS battery (Secure Battery
System) increase torsional rigidity. The result? The best possible driving experience thanks to precise, reliable handling - no matter what trail.
Size-specific stiffness
The asymmetric frame design allows Orbea to adjust the stiffness across all frame sizes. This means that tube lengths and breakaway torque change, but the ride quality of the Rise remains the same.
Long Vario seat posts
Steep'n'Deep has set a new standard in bike design. The large insertion depth allows the saddle to be lowered so far that it is not in the way when going downhill. This provides more freedom of movement and control. All frame sizes can accommodate dropper posts up to 200 mm, and frame sizes L and XL even have an insertion depth for Vario seat posts of up to 230 mm.
ORBEA RISE LT & RISE SL
The bike for shredders
Orbea Rise LT
The e-bike for trail shredders. Hit the road and expand your radius!
Orbea has increased the progression curve of the suspension to 23%. This makes it a very balanced ride for a trail bike and the chassis works well with both air and steel spring shock absorbers.
FORK 160 mm | SHOCK ABSORBER 150 mm | HEAD ANGLE 64 – 64.5°
The bike for flowing trails
Orbea Rise SL
The essence of trail riding. Experience the flow on every adventure!
The character of the suspension when pedaling (“anti-squat”) is tuned for optimal efficiency and makes it easier to get into the flow on fast single tracks.
FORK 140 mm | SHOCK ABSORBER 140 mm | HEAD ANGLE 65.5°
The same Rise experience, now in aluminum!
Rediscover your trails! The new Rise H offers the same natural riding feel and the
same features as the Rise Carbon.
The brand new aluminum frames are made with the highest quality techniques and materials
currently available. They are made of triple-butted aluminum, hydroformed
and have polished welds. In terms of performance and aesthetics, they are almost
identical to the respective carbon versions and the incomparable handling and the
optimal stiffness of the new Rise is ensured
MOTORIZATION
RS Power: Have more fun, more often
Rider Synergy (RS) is at the heart of the Rise. Orbea's bespoke firmware delivers natural, dynamic support to the Shimano EP801 and outstanding battery range for epic
bike adventure.
The new Rider Synergy. RS Gen2
“Less e more bike” means more natural support and more range. Orbea is convinced that such a great riding experience can only be achieved if you consider power and range in relation to each other, right from the start. Everything is in balance.
Performance and Natural Feeling
The Rise features next-generation firmware and electronics, allowing the motor power to be configured to up to 85 Nm . Thanks to the instant, delay-free support, the ride feels natural. In test rides, the ride feels even more natural at low cadence - for example on technical trails or challenging climbs. The Rise offers 15% more power at low cadence compared to the previous model.
driving modes
- The RS mode offers a maximum of 54 Nm of torque. It is designed for epic adventures
and supports naturally and dynamically in the cadence range in which
your body feels most comfortable. - The RS+ mode uses the full torque of 85 Nm. This creates a natural,
powerful ride when you pedal harder.
BATTERY
RS Range: Break the boundaries
“Less e,more bike” means you don’t have to worry about the range. The natural support of the RS Gen2 includes you in the support calculation, delivers exactly as much power as needed and saves battery elsewhere. 16% more range per gram : Orbea’s latest battery generation delivers more power without adding weight. The energy density is higher than any other battery on the market. This increases the range, but not the weight. Orbea test rides collect
With the larger batteries we often climb more than 3,000 meters on a single charge.
420 Wh battery
For low weight. If excellent handling and the lowest possible weight are important to you, the 420 Wh battery is the right choice -
With the help of the range extender, extended weekend trips are also possible.
ECO Approximate travel time 4 hours
TRAIL Approximate travel time 3 hours
BOOST Approximate travel time 2 hours
1.95 kg
630 Wh battery
For maximum range: If you want to go as far as possible, choose the 630 Wh battery. Since the rider’s weight also has a major impact on the
Since this affects the range of the battery, the 630 Wh variant is also suitable for heavier riders.
ECO Approximate travel time 6 hours
TRAIL Approximate travel time 4.5 hours
BOOST Approximate travel time 3 hours
2.9 kg
210 Wh range extender:
The new and improved range extender provides an additional 210 Wh. Simply place it in a bottle cage, plug it in and enjoy. The Rise uses the energy from the range extender first, which means you can remove it after use and keep riding.
ECO Approximate travel time 1.5 hours
TRAIL Approximate travel time 1 hour
BOOST Approximate travel time - not specified
1.05 kg
Orbea equipment variants
The Orbea e-bikes come in different equipment variants, with the letters and numbers in the model names such as H10, H30, M10, M30, M-Team and M-LTD indicating specific features and equipment levels. Here is a general explanation of the differences:
H-series (e.g. H10, H30)
The "H" here usually stands for "Hydro", indicating the use of aluminum frames. The models in this series tend to be cheaper and can therefore be accessible to a wider audience.
M-Series (e.g. M10, M30, M-Team, M-Ltd)
The "M" stands for "monocoque" and indicates the use of carbon frames. These models are usually lighter and more expensive than the H models.
Differences in equipment in detail
Rahmenmaterial
- H-series: aluminum frame
- M-Series, M-Team, M-LTD: Carbon frame
components
- The "10" models (H10, M10) have the best available components within their series.
- The "30" models (H30, M30) still have high quality but slightly cheaper components compared to the "10" models.
- M-Team and M-LTD models offer the absolute best and lightest components.
Preis
- M-series models, especially M-Team and M-LTD, are more expensive due to the carbon frame and premium components.
- H-series and team models are cheaper and aimed at a larger target group.
target group
- H-Series: Leisure riders and everyday users looking for good value for money.
- M-Series: More demanding riders who value performance and low weight.
- M-Team and M-LTD: Professional and sporty drivers who demand the highest performance and top components.
Conclusion on the Orbea Rise
The Orbea Rise represents a new era of e-mountain biking, where the boundaries between electric assistance and the traditional mountain bike experience are blurred. With its innovative approach, it offers an exceptional riding experience that will delight both experienced bikers and newcomers. If you are looking for an e-bike that combines performance, lightness and a natural riding feel, then the Orbea Rise is the perfect choice for you. Discover now how this exceptional bike can take your riding experience to a new level.
Orbea Rise
Break the boundaries!
